Rangeline 21PL
Specs & Features
Everything you need to know—from dimensions to features.
Size & Towing
- Exterior Length
- 20 ft 11in
- Exterior Width
- 8 ft 2.25 in (with Mirrors)
- Exterior Height
- 9 ft 5in (with A/C)
- Interior Width
- 5 ft 11 in
- Interior Height
- 6 ft 2.25 in
- Unit Base Weight
- 8,060 lbs
- Gross Vehicle Weight Rating (GVWR)
- 9,350 lbs
- Gross Combined Weight Rating (GCWR)
- 12,000 lbs
- Net Carrying Capacity (NCC)
- 1,290 lbs
- Hitch Weight
- 350 lbs
- Tow Capacity
- Up to 3,500 lbs (see Promaster guidelines)
- Features
- Class IV Hitch with 7-Pin Trailer Plug and Brake Control Wired
Chassis & Powertrain
- Chassis
- Ram ProMaster® 3500
- Drivetrain
- FWD
- Engine
- 3.6 L Pentastar® V6 24 V VVT Engine
- Transmission
- 9-Speed Automatic 948TE
- Wheelbase
- 159 in
- Horsepower / Torque
- 276 HP / 250 lb Torque
- MPG
- 18 - 20 Estimated Highway
- Emissions
- 50 State emissions
- Fuel Type
- Gasoline
- Fuel Tank
- 24 gal
- Suspension
- SUMOSPRINGS® on Front and Rear SUPERSPRINGS® on Rear
- Cab and Convenience Features
- 6-way Adjustable Driver/Passenger Swivel Seats
- 7 in TFT Color Display cluster
- Cockpit Carpet Floor Mats
- Google Android Auto/ Apple Carplay
- In-Dash Wireless Cell Phone Charging
- Multifunction Steering Wheel
- Remote Proximity Keyless entry
- UConnect 5 Nav with 10.1 in Touchscreen Display
Energy & Power
- Battery Capacity
- 3.5 kWh Deep Cycle Lithium Batteries with Built in Heater
- Solar Charging System
- 200 W Solar System
- Converter
- 130 A (Multi-Stage Charger)
- Inverter
- 3000 W (Pure Sine Inverter)
- Generator/Alternator
- 2.8 kW Ultra Quiet with Auto Start (Gasoline fueled)
- Shore Power
- 30 A Service with Smart Plug
- Multiplex System Display
- Multiplex Bluetooth App Control System with Touch Screen for Energy Management System
- USB Ports
- Cell-Phone Mount with Wired and Wireless Charging
Tank Capacities & Utility
- Fresh Water Tank
- 28 gal
- Gray Water Tank
- 19 gal
- Waste Tank
- 12 gal
- Holding Tank Disposal
- Gravity with Waste Tank Flush
- Heated Tanks
- Grey and Waste
Sleeping & Seating
- Sleeping Capacity
- Up to 4
- Convertible Sleeping Space
- 74 in x 57 in Motorized Lift Bed 74 in x 53 in Smartbench Sleeping Area
- Seating Capacity - Belted Positions
- Up to 4
- Features
- Multi-Positional Smartbench and Bed with Integrated Seatbelts
- Rear Curbside Bench Seating
- Telescoping Ladder
Climate & Comfort
- Air Conditioner - Primary
- 13,500 BTU with Soft Start
- Heating Source
- Timberline 2.0 Gas-Fired Hydronic
- Water Heating Source
- Timberline 2.0 Gas-Fired Hydronic
Galley
- Cooktop
- 1,000 W Single Burner Induction - Stowable
- Microwave
- 0.7 cu ft
- Refrigerator with Freezer
- 4.3 cu ft (12 V) Vitrifigo with Marker Board Front
- Galley Surface
- High Pressure Laminate Countertop with Aluminum Backsplash
- Sink & Faucet
- Stainless Steel Faucet
- Stainless Steel Sink with Cover
- Storage
- Integrated Storage Organization and Waste Basket
- Features
- Additional Dinette Table Mount
- Pop-Up Power Outlet
Dinette & Lounge
- Dinette
- Multi-Adjustable and Removable Dinette Table
Bathroom
- Configuration
- Space-Saving Wet Bath
- Toilet
- Macerating Toilet with Push Button Flush
- Shower
- Removable Hand Held Shower Head
- Shower Head with Flow Regulator
- Sink & Faucet
- Fold Down Sink with Integrated Faucet
- Vent/Exhaust Fan
- Exhaust Fan
- Retractable Clothes Line
- Standard
- Features
- In-Wall Storage Shelves
- Integrated LED Shower Lighting
- Shower Skylight
- Swinging Bath Door
- Wall Mounted and Pivoting Mirror
Entertainment & Connectivity
- Bedroom | Rear TV
- Prewired for TV
- Audio
- JBL Wireless Speaker with Locking Mount
- Bring Your Own Device Connection
- HDMI Pre-Wire
- Antenna Pre-Wiring
- Pre-wired for Connected Service
- Pre-wired for Satellite Dish
- Exterior Media Connection
- Exterior TV and Internet Inlets (Coax and Ethernet Cat6)
Interior Features
- Window Shades & Screens
- Black Canvas Window Coverings
- Front Cabin Window Covers
- Lighting
- 180 Degree Swivel LED Lighting
- Adjustable LED Lighting
- Storage
- Aluminum L-Track Floor Storage
- In-Wall Cubby Storage
- MOLLE Panels on Rear Doors
- Overhead Storage Compartments/Solutions
- Storage In Bed Bases and Under Bed
- Safety
- Smoke and CO2 Alarm | Fire Extinguisher
- Flooring
- Marine Woven Synthetic Flooring
- Rear Cabin Carpet Kit
- Exhaust Fan
- Multi-Speed Roof Mounted Vent Exhaust Fan
- Cabinetry
- Flush-Mount Cabinet Hardware and Soft Close Doors
- Matte Laminate Cabinetry
- Features
- 12 V Water Pump with Controller
- Custom Entryway Grab Handle
- Exterior-Side Galley Fold Down Table
- Signature Aluminum Ceiling and Trim
Exterior Features
- Style Elements
- Concealed Water Hookup Panel with LED Lighting
- Awning
- 13 ft Manual Awning
- Lighting
- LED Patio and Awning Lighting
- Step Lighting At Sliding Door
- Exterior Outlets
- Patio 120 V AC Outlet
- Exterior Shower
- Exterior Spray Port
- Tires
- Factory Alloy Wheels
- Windows & Entry
- Aluminum Powder Coated Running Boards
- Sliding Side Screen Door
- Zippered Screen Door System (rear)
- Features
- Winterization Valve
Membership & Warranty
- Airstream Warranty
- 2 Year Airstream Limited Warranty (Transferable)
- Chassis Warranty
- 3 Years/36,000 Miles RAM Basic Limited
- 5 Years/100,000 Miles Mercedes-Benz® Engine and Drive Train
- Airstream Club Membership
- 1 Year Airstream Club Explorer Membership
- Additional Benefits
- 1 Year 24/7 Coach-Net® Roadside Assistance
Additional
- Certification
- TRA Certification™ Green: Emerald Status (Highest Rating)
