Icon_ArrowLeft2026 Basecamp® starting at $53,700
2026 Basecamp® Icon_ArrowDown

Basecamp Specs

Select Floor Plans to Compare Specs

Specs
Basecamp 16X Basecamp 20X
Basecamp 16X Basecamp 20X
Exterior Length 16 ft. 2 in. – 20 ft. 2 in. – Details Details Details Details
Exterior Width 7 ft. – 7 ft. 9.5 in. – Details Details Details Details
Interior Width 6 ft. 4.5 in. – 7 ft. 2.5 in. – Details Details Details Details
Exterior Height with A/C 8 ft. 8.75 in. – 9 ft. 1.5 in. – Details Details Details Details
Maximum Trailer Capacity GVWR (lbs.) 3,500 – 4,300 – Details Details Details Details
Cargo Capacity NCC (lbs.) 850 – 900 – Details Details Details Details
Fresh Water Tank (gal.) 21 – 23 – Details Details Details Details
Gray Water Tank (gal.) – – 28 – Details Details Details Details
Waste Water Tank (gal.) 24 (Combo) – 21 – Details Details Details Details
Ducted Furnace (BTU) 12,000 – 19,000 – Details Details Details Details
Convertible Dinette, Lounge and Bed (inches) – – 43 – Details Details Details Details
Interior Height with A/C (Entry Area) 6 ft. 3.5 in. – 6 ft. 7 in. – Details Details Details Details
Microwave OPT (0.7 cu. ft.) – OPT (0.7 cu. ft.) – Details Details Details Details
Exterior Height without A/C 8 ft. 7.5 in. – 8 ft. 10 in. – Details Details Details Details
30 AMP Service Single A/C with Heat Strip (BTU) OPT (9,200) – OPT (13,500) – Details Details Details Details
Hitch Weight with LP & Batteries (lbs.) 410 – 500 – Details Details Details Details
Unit Base Weight with LP & Batteries (lbs.) 2,650 – 3,400 – Details Details Details Details
Interior Windows & Skylights 8 – 8 – Details Details Details Details
Sleeping Capacity (excludes optional tents) Up to 2 – Up to 4 – Details Details Details Details
Refrigerator with Freezer (12v Electric) 3.1 cu. ft. – 4.3 cu. ft. – Details Details Details Details
Solar Charging System with Interior Monitor OPT 200W – OPT 300W – Details Details Details Details
LP Gas Stove (Burners) 2 – 2 – Details Details Details Details
Internal Lithium Batteries with Remote Monitoring (Only Available with Solar Options) OPT 2.5kWh – OPT 2.5kWh – Details Details Details Details
Convertible Bench Seating & Bed Dimensions Seating (24 in. x 76 in.) Half Bed (38 in. x 76 in.) Complete Bed (76 in. x 76 in.) – Seating (26 in. x 78 in.) Half Bed (41 in. x 78 in.) Complete Bed (82 in. x 78 in.) – Details Details Details Details
Exterior Details Details
Single Direct Discharge A/C with Heat Strip and Electric Thermostat OPT – OPT – Details Details Details Details
12v Tank Heaters (In Addition To Heated Underbelly) STD – STD – Details Details Details Details
2 Heavy Duty Stabilizer Jacks STD – STD – Details Details Details Details
200W Solar Charging System with Interior Monitor OPT – – – Details Details Details Details
200W Solar Charging System with Interior Monitor & 2.5kW Heated Lithium Batteries OPT – – – Details Details Details Details
300W Solar Charging System with Interior Monitor – – OPT – Details Details Details Details
300W Solar Charging System with Interior Monitor & 2.5kW Heated Lithium Batteries – – OPT – Details Details Details Details
Aluminum Entry Door Handle STD – STD – Details Details Details Details
Cast Aluminum LED Tail Lights STD – STD – Details Details Details Details
City Water Inlet w/ Water Pressure Regulator STD – STD – Details Details Details Details
Custom Aluminum Handcrafted Entry Door with Window STD – STD – Details Details Details Details
Custom Molded Plastic LP Cover w/ Storage Tray STD – STD – Details Details Details Details
Dedicated Sewer Hose Storage STD – STD – Details Details Details Details
Enclosed Aluminum Insulated Heated Underbelly STD – STD – Details Details Details Details
Exterior LP Gas Low Pressure Grill Connection STD – STD – Details Details Details Details
Exterior Shower with Hot and Cold Water – – STD – Details Details Details Details
Exterior Shower with Hot and Cold Water (Pass Through) STD – – – Details Details Details Details
Fluorocarbon Treated UV Protected Aluminum Exterior STD – STD – Details Details Details Details
Full Size Spare Tire STD – STD – Details Details Details Details
Goodyear® Off Road Durotec® LT235/85R16E, Balanced – – STD – Details Details Details Details
Goodyear® Wrangler Trailrunner® ST235/75R15E, Balanced STD – – – Details Details Details Details
Hand Crafted Welded Extruded Aluminum Window Frames STD – STD – Details Details Details Details
Hand Painted Chassis STD – STD – Details Details Details Details
Insulated and Heated Tanks (Forced Air and 12V Heat Pads) STD – STD – Details Details Details Details
Internally Routed A/C Condensation Drain Line to Wheel Well STD – STD – Details Details Details Details
LED Entrance Light STD – STD – Details Details Details Details
LED Tank Service Light STD – STD – Details Details Details Details
License Plate Bracket with LED Light STD – STD – Details Details Details Details
Lockable Fresh Water Tank Inlet STD – STD – Details Details Details Details
LP (2 – 20 lb. Steel Tanks) w/ auto 2-stage regulator STD – STD – Details Details Details Details
Multi-Stage 50A Converter STD – STD – Details Details Details Details
Nev-R-Adjust® Brakes STD – STD – Details Details Details Details
Powered Hitch Jack with Light STD – STD – Details Details Details Details
Rooftop Solar Pre-Wire Port (Factory Installed for Solar Upgrade) STD – STD – Details Details Details Details
Seamless Composite Flooring STD – STD – Details Details Details Details
Semi-Monocoque Aluminum Superstructure STD – STD – Details Details Details Details
SmartPlug® 30 Amp Shore Power Inlet with Cord STD – STD – Details Details Details Details
Solar Front Window Protection STD – STD – Details Details Details Details
Stainless Steel Front Stone Guard Protection STD – STD – Details Details Details Details
Steel Double Entry Step – – STD – Details Details Details Details
Steel Single Entry Step STD – – – Details Details Details Details
Stylized Aluminum Wheels STD – STD – Details Details Details Details
Supplemental Solar Pre-Wire Port 200W Capacity (15A Controller Required) STD – STD – Details Details Details Details
Tempered Tinted Windows with Screened Rear Venting Windows STD – STD – Details Details Details Details
Thermal Barrier Protection Between Interior and Exterior STD – STD – Details Details Details Details
Torsion Axle with Shock Absorbers STD – STD – Details Details Details Details
Unique Front Door Key w/ Heavy Duty Deadbolt STD – STD – Details Details Details Details
Waste Tank Flush Inlet – – STD – Details Details Details Details
Interior Details Details
12v Auxiliary Power Outlet STD – STD – Details Details Details Details
Airstream Connected Pre-wire STD – STD – Details Details Details Details
Aluminum L-Track Storage System (Floor) STD – STD – Details Details Details Details
Coat & Key Hooks STD – STD – Details Details Details Details
Complete Aluminum Interior Walls and Ceiling STD – STD – Details Details Details Details
Direct Spark Ignition / LP Water Heater STD – STD – Details Details Details Details
Handcrafted Marine-Grade Lite-Ply Laminated Cabinetry STD – STD – Details Details Details Details
LED Interior Lighting STD – STD – Details Details Details Details
Multi-Speed Roof Exhaust Fan STD – STD – Details Details Details Details
Overhead Storage STD – STD – Details Details Details Details
Panoramic Front Windows with Blackout Shades STD – STD – Details Details Details Details
Premium Environmental Friendly Insulation STD – STD – Details Details Details Details
Probeless Tank Monitoring System STD – STD – Details Details Details Details
Rear Floor Storage Compartment w/ Drain Plug – – STD – Details Details Details Details
Seamless Vinyl Flooring STD – STD – Details Details Details Details
Sliding Screen Entry Door and Removeable Zippered Rear Screen STD – STD – Details Details Details Details
Tankless On Demand LP Water Heater STD – STD – Details Details Details Details
Tie Down D-Rings STD – STD – Details Details Details Details
Galley, Dinette, Lounge Details Details
2 Additional Short Aluminum Pedestals for Bed Conversion STD – STD – Details Details Details Details
2 Burner Stove (LP Gas) STD – STD – Details Details Details Details
2 Movable Laminate Table Tops with Aluminum Pedestals STD – STD – Details Details Details Details
Convertible Lounge and Sleeping Accommodations STD – STD – Details Details Details Details
Dedicated Table Storage STD – STD – Details Details Details Details
Durable Stain Resistant Cushions STD – STD – Details Details Details Details
Flatware Organizer STD – STD – Details Details Details Details
Graphite Black Faucet STD – STD – Details Details Details Details
Laminate Galley Top STD – STD – Details Details Details Details
Microwave OPT – OPT – Details Details Details Details
Pop Up 110v USB and Standard Outlets STD – STD – Details Details Details Details
Stainless Steel Sink w/ Integrated Cover STD – STD – Details Details Details Details
Bedroom Details Details
12v USB-A and USB-C Ports STD – STD – Details Details Details Details
Blackout Curtain(s) STD – STD – Details Details Details Details
Cargo LED Light STD – STD – Details Details Details Details
Convertible Lounge, Storage & Sleep Accommodations STD – STD – Details Details Details Details
Lockable Storage with USB STD – – – Details Details Details Details
Under Bed Storage STD – STD – Details Details Details Details
USB Ports STD – STD – Details Details Details Details
Bathroom Details Details
Basecamp Shower Caddy STD – STD – Details Details Details Details
Removable Hand Held Shower Head w/ Shut Off STD – STD – Details Details Details Details
Retractable Clothes Line in Shower STD – STD – Details Details Details Details
Roof Vent/Fan STD – STD – Details Details Details Details
Toilet STD – STD – Details Details Details Details
Towel Bar/Hooks STD – STD – Details Details Details Details
Window with Privacy Curtain – – STD – Details Details Details Details
Additional Details Details
1 Year Airstream Club Explorer Membership STD – STD – Details Details Details Details
2 Year Bumper-To-Bumper Airstream Limited Warranty (Transferable) STD – STD – Details Details Details Details
3 Year 24/7 Coach-Net® Roadside Assistance STD – STD – Details Details Details Details
5 Year Structural Limited Warranty (Transferable) – – STD – Details Details Details Details
Airstream Logo Entrance Mat STD – STD – Details Details Details Details
Built In Winterization Kit STD – STD – Details Details Details Details
Emergency Manual Crank for Powered Hitch Jack STD – STD – Details Details Details Details
Fire Extinguisher STD – STD – Details Details Details Details
Fully Enclosed Tent with Air Tube Technology (Parts Department) OPT – OPT – Details Details Details Details
LP Low Pressure Gas Grill Connection STD – STD – Details Details Details Details
LP, Smoke & Carbon Monoxide Detectors STD – STD – Details Details Details Details

Specifications, dimensions, measurements, weights, capacities and other numbers on this website are approximates based upon design and engineering drawings, prototypes and laboratory tests. Your vehicle may differ due to variations in manufacture and equipment. Please check with your Airstream dealer for complete details.
